GEOTEXTILE FABRIC 1M X 50 METRE ROLL PER METRE x1

Bidim® C conductive non-woven geotextile is the world’s first commercial conductive non-woven geotextile. It is made with a two-dimensional sheet of carbon atoms, considered to be the lightest, strongest, and most electrically conductive substance yet discovered.

Bidim C has been designed to provide effective and economical leak detection means for designers and installers of geomembrane lining systems, including landfills, tailings dams, tanks, and potable water storage facilities. It enables leak detection surveys to be carried out using an electrical leak location technique known as Arc testing, providing reliable leak detection of holes and defects as small as 0.2mm.

 Using Bidim C mitigates the need for water compared to conventional leak detection surveys as the electrical circuit can be completed without relying on a wet subgrade. This technology is particularly efficient in dual lining applications and/or when installed below the primary liner and above a geocomposite layer that separates the subgrade from the liner. Bidim C features a strong three-dimensional structure with high elongation, providing excellent filtration and also performing as a cushion to the subgrade.
